Automatic DD Saw Machine

Nihar Industries is a leading designer, producer and supplier of top grade automatic DD saw machines that can deliver stellar performance each and every time. The state of the art automatic DD saw machines offered by Nihar Industries can be used for effectively trimming the rough edges and make required size in all types of wooden boards and plywood boards. The machine comes with four circular saws that are equipped with four motors. The automatic DD saw machines can also be used extensively for MDF boards, block boards, particle boards and other materials. Such aspects make them highly versatile saw machines.
The automatic DD saw machines are fitted with gear box system. The electric panel can be of great help to the users which can assist in running the machines. The saw blade diameter of these machines is between 250 mm and 315 mm. The thickness of sawing board is around 2.7 mm to 60 mm. The main saw has got a rotational speed of 6500 rpm. The overall dimensions that are associated with these machines are 8500 mm x 5530 mm x 1420 mm. The motors that are fitted to these machines have got an excellent range and can deliver powerful results on a consistent basis.

Techincal Specification of Automatic DD Saw Machine

DescriptionAutomatic DD SAW
Saw Blade DiameterФ250 mm – Ф315 mm
Thickness of The Sawing Board2.7mm – 60mm
Cut SizeWidth – Min. 762mm(30”) to Max. 1220mm (48”)
Length – Min. 1830 (72”) to Max. 2440mm (96”)
Rotational Speed of The Main Saw6500 Rpm
Overall Dimensions8500mm x 5530mm x 1420mm
Power11KW (15HP)x 2800 RPM – 2 NOS
7.5KW (10HP) x 2800RPM – 2 Nos.
1.5 KW (2HP) x1440 RPM – 2 Nos
0.75KW (1HP) x 1440 RPM – 2Nos.
Control MethodPLC Control System
Cutting Size AdjustmentBy PLC Control
Table lifter With Stacker (Scissor Lift)1set with Hydraulic Powerpack (5HP)
Red Laser2Set (4 Piece)
Working Dry Air Pressure0.4 to 0.8 Mpa

*Specifications are subjected to change without notice.

Silent Features

  • Nanxing has invested hundreds of millions for taking in 500 world best CNC and robot machines for metal works, making its production ranked No. 1 in thewoodworking machinery industry. SOP professional assemble lines.
  • Powerful SYNTECH CNC CONTROL SYSTEM equipped with specialist software to runfor high process efficiency and easy operation, the fastest in the field.
  • Adapt 7 kinds of file format and common furniture design software.
  • Customer Reference: 30+ countries; 2000+ machines

Download Catalogue

Applications of Automatic DD Saw Machine

The Wide Belt Sander Machines created by Nihar Industries are some of the best in the industry as they are capable of offering substantial output every time. They are also suitable for projects that come with major customization requirements.
  • Wood Sanding
  • Ply Sanding
  • Wood Calibration
  • Ply Calibration
